CT X-RAY TUBE

CTR2200 series

DUNLEE CTR22xx

EXCELLENT IMAGE QUALITY MEETS FLEXIBILITY

The CTR2200 series tubes offer a wide range of features for flexibility and are especially well suited for advanced CT applications. We can adjust these features and customize a tube to meet your individual needs in the CT advanced performance segment. Based on a tried and true design, the tube offers a long lifetime and low maintenance costs.
KEY BENEFITS

Superb image resolution

  • X- and Z-deflection reduce image artefacts for high image resolution
  • Z-deflection enables doubling of slices for increased image quality



Continuous patient throughput

  • Features high anode heat storage for scanning a large number of patients
  • Fast gantry rotation enables shortened scan times



Outstanding design

  • Reliable design for exceptional system quality
  • Tube designed for easy and convenient system integration

We provide solutions that also meet ambitious needs for our customers‘ success.



With our extensive knowledge of X-ray tubes, high-voltage generators, X-segments and integrated imaging solutions, we are able to help you select the right components for your application during the development phase and provide support throughout the entire product lifecycle.

Specifications CTR2200 series

Maximum Power [kW]

(IEC Rated (4/600 sec repeated)

50 - 80

Maximum Nominal Gantry Speed [rpm]

(@570mm FS to ISO distance)

Up to 120 - 151
Maximum G-Force for Operation [g]
Up to 11 - 17.5
Nominal Tube Voltage [kV]
140
Focal Spots [mm]
Large
Small
1.1 x 1.2
0.6 x 1.2
Dynamic Focal Spot
X-DFS
Z-DFS
Yes
Yes
Polarity
Bipolar
