EXPLORE THE POSSIBILITIES OF MANUFACTURING WITH TUNGSTEN



Tungsten, prized for its density and durability, is of increasing interest to manufacturers in a variety of markets, particularly because additive manufacturing is expanding its potential applications. As owner of the world’s largest printer park dedicated to tungsten, Dunlee is at the forefront of developing products and components with this useful material.

Dunlee Video Tungsten

Tungsten characteristics



Determining the right material for your product or component begins by assessing a material’s property specifications and comparing those to the needs of your product. If you need a material that offers any of these characteristics, then tungsten is worthy of your consideration.



Contact a Dunlee consultant to discuss if tungsten is right for your application.

Radiation absorption

Density of 19.3 g/cm3
(1.7 times higher than lead)

Heat resistance

Extreme heat resistance and a melting temperature of 3422° C

Tensile strength

Above 1650° C

Long life

High resistance to wear

Sustainable

100% recyclable

Magnetism

None

Size and tolerances



One of tungsten’s advantages is its ability to be used in products of diverse sizes and tolerances. The tolerances listed are guidelines only; they vary based on design and application. Please contact Dunlee at marketing.dunlee@​philips.com to discuss your needs.

Maximum size

230 x 230 x 200 mm
(larger possible through innovative solutions)

Feature positions

25 µm within an area of 50 x 50 mm2
30 µm within an area of 100 x 100mm2
50 µm within an area of 150 x 150 mm2
(maximum build area; dependent on design and tolerances)

Wall thickness

Minimum of 80 µm walls with 25 µm tolerance

Surface roughness

Assume an Ra of 6.3 after post-processing

Parallelism

50 µm for wire EDM defined surfaces*

Flatness

50 µm for wire EDM defined surfaces*

*Impacted by overall outside dimensions

Learn more about tungsten’s potential in your industry.

hotspots

    • Tungsten in Aerospace



      Key advantage: Radiation shielding



      Possible applications:



      • Ignition chambers for rocket engines
      • Combustion chambers
      • Counter-weights
      • Radiation shielding

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Baggage Scanning



      Key advantage: Radiation absorption for image quality



      Possible applications:



      • X-ray XRF

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Mining



      Key advantage: Radiation shielding



      Possible applications:



      • Collimator shields and flange lids
      • Mimir XRF shields and lids
      • XRF shields and XRF radiation shields
      • X-ray source front cover shields
      • Anti-scatter grids
      • Calibration pallets

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Watchmaking



      Key advantage: Density



      Possible applications:



      • Counter-weights

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Automotive



      Key advantage: Heat resistance



      Possible applications:



      • Heat exchangers
      • Counter-balance weights
      • Heat shields



      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Gamma Ray Applications



      Key advantage: Radiation absorption



      Possible applications:



      • Anti-scatter grids
      • Pin-hole collimators

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Nuclear Fusion



      Key advantage: Heat resistance



      Possible applications:



      • Heat exchanger (stand-alone or hybrid)

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in X-ray Tubes



      Key advantage: Radiation shielding



      Possible applications:



      • Anodes
      • Drive components
      • Cathodes

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Aviation



      Key advantage: Density



      Possible applications:



      • Counter-weights
      • Anti-vibration parts
      • Parts to balance rotor blades

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Glass Making



      Key advantage: Heat resistance



      Possible applications:



      • Sensor housing
      • Nozzles

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    • Tungsten in Oil and Gas



      Key advantage: Hardness and wear-resistance



      Possible applications:



      • Drill heads

      By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.

      I understand

      You are about to visit a Philips global content page

      Continue

    ARE YOU READY TO EXPLORE?



    If you’d like to discuss a potential application for additive manufacturing with tungsten or if you’d just like to learn more about its properties, just send us an email at marketing.dunlee@​philips.com and a member of our business development team will contact you.
